Technical
College-Misayyab, Al-Furat Al-Awsat Technical University discussed a master
dissertation on an analytical comparison of a single-phase multi-speed
induction motor using the finite element method by the postgraduate student,
Mr. Mohammed Jassim Hassan Al-Saadi.
The dissertation
aimed at using the capabilities of the Ansys program in its two branches RMxprt
/ Maxwell2D to study the effect of any change in the motor design on the motor
performance of a single-phase multi-speed 0.25 hp induction motor.
The dissertation
confirmed that the numerical model using finite element analysis (two
dimensions) for this type of motor gives the inductor an accurate determination
of the motor performance, and the motor's behavior can be predicted when
changing the values of the additional capacitor or the air gap between the
fixed part and the rotating part, as well as the deviation of the rotor bars.
The dissertation
recommended the possibility of improving the (two-dimensional) analysis that
was conducted for this motor to become a (three-dimensional) analysis, as well
as conducting the associated electromagnetic thermal analysis to determine the
temperature distribution inside the machine.
